Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System

Quantité de commande min : 2 unité Prix : négociable
Détails d'emballage : Cas en bois et boîtier en carton Délai de livraison : 7-15 jours ouvrables
Conditions de paiement : T/T Capacité d'approvisionnement : 10000 unités par mois
Lieu d'origine: Hunan, Chine Nom de marque: Chalong Fly
Certification: CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc Numéro de modèle: CLFLE218

Détail Infomation

Type de batterie:: Batterie LifePO4 tension:: 96v
Capacité:: 300h Taille:: Personnalisé
OEM / ODM:: Oui Package de transport:: Caisse de mousse et de contreplaqué
Norme d'étanchéité:: IP67 Code HS:: 8507600090
Caractéristiques:: Résultat rentable, livraison rapide, structure stable Application:: véhicule électrique, bateau électrique, yacht électrique, marine
Mettre en évidence:

Customized Size Marine Lithium Battery

,

Stainless Steel Case LiFePO4 Battery

,

Thermal Management System Lithium Battery Pack

Description de produit

OEM ODM LiFePO4 30kwh marine battery pack 96V 300Ah lifepo4 battery for electric boat


If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.


Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.



Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 0Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 1

Product Parameter
MODEL
96300
Cell Type - Chemistry
Prismatic- LiFePO4
Rated Capacity
304Ah
Rated Voltage
96V
Energy
29.18KWh
Resistance
30mΩ
Self Discharge
<3% per month
PDU
BMS, 400A relays, fuses, COM socket
Dimensions (L x W x H)
L1300*W500*H380mm
(Can make it smaller if you want)
Weight
2540Kg
Enclosure Protection
IP67 stainless steel case
Discharge Cut-off Voltage
75V
Max Continuous Discharging Current
300A
Peak Discharge Current
400A for 60 seconds
Recommended Discharge Current
300A
Charging Limited Voltage
109.5V
Max Charging Current
200A
Recommended Charge Current
100A
Charge Temperature Range
0~50℃
Discharge Temperature Range
-20~60℃
Recommended Operating Temperature
15~35℃
Available on request
Size, C rate, Communication protocol

Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 2

Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 3

Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 4

Optional thermal management system
liquid cooling and heating system can adapt the battery to different working environment
temperatures .Battery thermal management systems are designed to regulate the temperature of batteries in electric vehicles or other battery-powered systems. It is good in maintaining the overall health and performance of batteries. that helps maintain the optimal temperature to ensure optimal battery performance.

Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 5Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 6Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 7

Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 8Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 9Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 10Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 11Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 12Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 13Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 14Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 15Customized Size 96V 300Ah Marine Lithium Battery with Stainless Steel Case and Thermal Management System 16


FAQ:

Q1. Are you a factory?

A: Yes, we are a professional lithium battery manufacturer in China, and factory tour is acceptable.


Q2. Do you accept OEM/ODM?

A: Yes, OEM, ODM, LOGO, and STICKER is acceptable, our professional team is on hand to offer you any solutions.


Q3. Can I have a sample order first?

A: Yes, sample order is acceptable.


Q4. How will my order be shipped?

A: Chalong Fly offers a variety of shipping methods, such as DHL, UPS, FedEx, TNT, Airline and sea shipping.


Q5: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.


Q6. Can we sign a NDA in order for a long-term cooperation?

A: Yes, the client’s requirements is respected.


O7: Is there any warranty or After-Sale Service?

A: We will check each battery before shipment, and 100% high quality guaranteed. The warranty is about 1~20 years depends on different models.


Q8. Why do you choose Chalong Fly?

A: Chalong Fly R&D center has more than 60 R&D engineers, 12 of whom have more than 10 years of experience related to power development. We have a deep understanding of power electronics technology, and a full understanding of the needs of the application industry, and have developed many public technology solutions.
