Appareil de stockage de l'énergie pour l'industrie et le commerce
ContPerson : Rosa Liu
Numéro de téléphone : +86 18975107916
Quel est l'app? : +8618975107916
| Quantité de commande min : | 2 unités | Prix : | négociable |
|---|---|---|---|
| Détails d'emballage : | Cas en bois et boîtier en carton | Délai de livraison : | 7-15 jours ouvrables |
| Conditions de paiement : | T/T | Capacité d'approvisionnement : | 10000 unités par mois |
| Lieu d'origine: | Hunan, Chine | Nom de marque: | Chalong Fly |
|---|---|---|---|
| Certification: | CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc | Numéro de modèle: | CLFLE218 |
|
Détail Infomation |
|||
| Type de batterie :: | batterie lifepo4 | tension:: | 51,2 V |
|---|---|---|---|
| Capacité:: | 105Ah | Taille:: | Personnalisé |
| OEM / ODM:: | Oui | Package de transport:: | Caisse de mousse et de contreplaqué |
| Norme d'étanchéité:: | IP67 | Code SH :: | 8507600090 |
| Caractéristiques:: | Résultat rentable, livraison rapide, structure stable | Application:: | BOATS, chariots de golf, véhicules électriques, voiture de golf |
| Mettre en évidence: | 24V 300Ah LiFePO4 RV battery,7.2kWh high-capacity RV battery,LiFePO4 portable energy storage system |
||
Description de produit
| Specification | Value |
|---|---|
| Electrical | |
| Nominal Voltage | 24V (25.6V) |
| Nominal Capacity | 300Ah |
| Rated Energy | 7200Wh (7.2kWh) |
| Cell Type | Prismatic LiFePO₄ (Grade A) |
| Cycle Life | ≥5000 cycles @80% DoD to 70% capacity |
| Max. Continuous Charge Current | 75A |
| Max. Continuous Discharge Current | 150A |
| Peak Discharge Current | 450A (≤3s) |
| Charge Voltage Range | 28.8V – 29.2V |
| Discharge Cut‑off Voltage | 20V ± 0.5V |
| BMS | |
| BMS Type | Built‑in smart BMS with active balancing |
| Balancing Current | 1.2A (active) |
| Protection Features | Over‑voltage, under‑voltage, over‑current, short‑circuit, over‑temperature, under‑temperature, cell imbalance |
| Communication (standard) | CAN, RS485, Bluetooth (optional) |
| Low‑temp Heating (optional) | Self‑heating pad, starts at <0°C, stops at 10°C |
| General | |
| Operating Temperature (Discharge) | -20°C to 65°C |
| Operating Temperature (Charge) | 0°C to 55°C (with heating: -20°C to 55°C) |
| Storage Temperature | -10°C to 45°C |
| IP Rating | IP54 (standard) / IP65 (upon request) |
| Dimension (L*W*H) | Approx. 660*240*240 mm (depends on brand) |
| Weight | Approx. 58‑65 kg |
| Terminal Type | M10 |
| Enclosure Material | Steel with powder coating |
| Certifications | CE, RoHS, UN38.3, MSDS |
The 24V 300Ah LiFePO₄ battery is the energy core designed for high‑consumption RVs, converted buses and off‑grid homes. With 7.2kWh of total energy, it can power a 2000W induction cooktop for 1 hour, a 1200W RV air conditioner for 5‑6 hours, plus auxiliary devices like fridge, lights and water pump all day long. Using Grade A LiFePO₄ cells and an active balancing BMS, each cell string is kept in optimal condition, greatly extending cycle life and safety margins.
![]()
| Scenario | Description |
|---|---|
| Large RVs / Bus Conversions | Powers high‑draw appliances: induction cooktop, microwave, roof AC, water heater, washer/dryer |
| Off‑grid Cabins | 7.2kWh per unit – 6 units in parallel provide up to 43.2kWh for week‑long autonomy with solar |
| Home Backup (Critical loads) | Keeps fridge, freezer, medical devices, sump pump running during outages |
| Boat / Marine (48V hybrid) | Two units in series (with proper BMS) for 48V systems in electric yachts |
| Workshop / Mobile Office | Silent power for tools, computers, communication equipment |
![]()
![]()
Q: Can it directly replace the original lead-acid battery?
A: Yes, 12.8V is compatible with 12V systems, with adaptive size and consistent positive and negative poles, plug and play; it is recommended to check if the charger supports LiFePO4 (14.4V-14.6V).
Q: Does it support parallel expansion with multiple batteries?
A: Yes, it can be paralleled with up to 4 batteries, with a total capacity of 1600Ah, meeting the demand for large loads.
Q: Can it be used in low temperatures in winter?
A: The standard version can be charged above 0℃; the optional low-temperature heating version can be normally charged and discharged at -20℃, suitable for RVs in northern winter.
Q: How long is the service life and warranty period?
A: 3000+ cycles (70% DOD), usable for 8-10 years under normal use; 5-year warranty (free of charge for non-human damage).
Q: Is maintenance required?
A: Zero maintenance, no need for water replenishment, balancing or regular charging, low self-discharge rate, and slow power loss during long-term storage.
Q: Is it safe? Will it explode?
A: It adopts LiFePO4 (lithium iron phosphate), which has stable chemical properties, non-flammable and non-explosive; built-in BMS multiple protection and flame-retardant shell, safe and reliable for RV use.
